Airtght Automatic Door

Airtght Automatic Door Genernal Description

This series of door design is according to GMP design and safety requirements. It is a custom airtght automatic door and design for hospital operating room, hospital ward area, kindergarten. Select high efficiency brushless DC motor with small size, large power, low noise and long life. High quality sealing gasket is inlaid around door leaf, close to door sleeve when closed, with good air tightness.

Major Advantage Highlights

1. Smooth transition design, smooth surface

2. Sturdy and durable, anti-collision, easy to clean

3. Anti-collision, wear-resistant, anti-bacterial, moisture-proof

4. Stable operation and low noise

Free Consultation

FEATURES

Performance / Characters
Normal width of door hole(mm) Single door Double door
900/1000/1500 ≤3000
Normal height of door hole(mm) 2100
Opening angle ≥50
Type Wall door
Wall thickness(mm) ≥50
The type of panel Colored GI panel,SUS panel,HPL
Door leaf thickness(mm) 40
Observation window size (mm) HPL 400×600
Colored GI panel 450×650
The type of lock Hidden handle,SUS handle
Access Control Electric door system

Detailed Pictures

Guide Rail

Guide Rail

Hanging wheel

Hanging wheel

Hidden handle

Hidden handle

Panle

Panle

Observation window

Observation window

Safe light

Safe light

Balance wheel

Balance wheel

Hardwares & Accessories

1. Hardware Options

Angle Sample Picture Description Brand Name Model Number Adjustment Method Specificaion / Features
Hardware Options
For sliding door system, permanent magnet motor is the best choice. Permanent magnet DC motor converts electrical energy into mechanical energy through the interaction of two magnetic fields. Sliding automatic door motor / Remote control to set The brushless DC motor adopts internal control anti-sound seal design, with large torque, high speed, low noise, and no heat for long-term use.
Hardware Options
Lithium battery automatic door backup power supply is a backup emergency power supply specially designed for automatic doors. It is very suitable for automatic door applications that are troubled by power outages, so that automatic doors can work normally after a power failure (about 550 times of normal opening and closing, and about 7 hours of normal use) ) Or in accordance with the fire evacuation requirements, make the automatic door open automatically after a power failure. Lithium battery automatic door backup power supply / Adopt microcomputer discharge management Power failure normal work and power failure open.
Hardware Options
Automatic door electric lock bracket is specially used for fixing electric bolt lock of automatic door; suitable for various door machine guide rails. Automatic door electric lock bracket / Manual adjustment Stainless steel material, simple and clear structure, stable and reliable installation.



2. Handle / Knob

Angle Sample Picture Description Brand Name Model Number Adjustment Method Specificaion / Features
Handle / Knob
The handle is a component used to easily open and close the door on the door body, and the form and function of the handle in the industrial box are very many, and the quality is better than that of the ordinary handle. Handle / Manual operation Strong and aesthetically pleasing and easy to clean.
Handle / Knob
The handle is a component used to easily open and close the door on the door body, and the form and function of the handle in the industrial box are very many, and the quality is better than that of the ordinary handle. Stainless steel handle / Manual operation Stainless steel handle has good strength, strong corrosion resistance, non-radioactive, smooth surface, easy to clean, and beautiful appearance.



3. Glass Options

Angle Sample Picture U-factor Solar Heat Gain Coefficient Vision Light Transmitance UV Protection Anti-Explosion Denoise
Single Glass ★★★☆ ★★★☆ ★★★☆ ★★★☆ ★★★☆ ★★★☆
Double Glass ★★★☆ ★★★☆ ★★★☆ ★★★☆ ★★★☆ ★★★☆



4. Other Accessories

Angle Sample Picture Description Brand Name Model Number Adjustment Method Specificaion / Features
Other Accessories
The hand sensor switch can be used in all non-contact control entrance and exit sensor control, easy to operate and prevent hand contact pollution. Hand sensor switch / Hand induction No touch, fast response.
Other Accessories
Foot reaction switch
is a kind of switch by foot or foot to control the circuit on and off, used in the hands can not touch the control circuit to replace the hands to achieve the purpose of operation.
Foot reaction switch / Foot sensing Management software: powerful, automatic upgrade
Induction control, easy to operate,replace with feet, prevent hand contamination.
Other Accessories
Face recognition switch is the use of face recognition technology to collect photos and photos have been saved, ID photos are compared and provide face similar value, the staff can judge whether to directly pass or manually audit according to the level of similar value. Face recognition switc / Human body induction Easy and quick: Don't press, just look.
